Measuring Tools

> TMT46004

TMT46004 DC/AC Clamp Meter

Share with QR

Measuring Tools

> TMT46004

TMT46004 DC/AC Clamp Meter

Industrial

CATIII 600V

Display True RMS 6000 Counts

Features,

Backlight and Flash Light Indicator

Data Hold

Diode Test

Temperature

Low Battery Indicator

Specifications
Model no. TMT46004
Voltage DC: 600V ±(0.5% +3), AC: 600V ±(0.8% +5)
Current DC: 60A / 600A ±(2.5% +5), AC: 6A / 60A / 600A ±(2.5% +8)
Rated duty cycle 1%~99% ±(1.0% +2)
Resistance 6kΩ / 60kΩ ±(1.0% +3)
Reading Capacitance: 10nF / 100nF / 1nF / 10uF / 100uF / 1mF / 10mF / 100mF ±(4.0% +3)
